35010 PRESS VISE WITH LOCK DOWN JAW MECHANISM
● Lockdown jaw mechanism, eliminates jaw lifting and work-piece titling.
● High tensile cast iron (FC25).
● Vise bottom and sliding ways are precision ground.
● Step jaw plates are hardened to HRC52 and precision ground.
● Precision lead screw supported by steel balls design for smoother movement.
● Surface of vise bed parallel to bottom of vise body within 0.03m/m.
● Jaw plate to sliding ways square within 0.03m/m.
unit：mm
| Order No. | Model | Jaw Plate Height | Jaw Plate Width | Opening | Weight (kg) |
| 35010-10 | DV-100(4") | 43 | 100 | 90 | 6 |
| 35010-13 | DV-130(5") | 44 | 130 | 100 | 8.2 |
| 35010-16 | DV-160(6") | 44 | 160 | 105 | 10 |
